BICICLETA HAIBIKE TRIA 10

Bike Geometry
Bottom bracket drop [mm]:
0 mm
Chain stay length [mm]:
480 mm
Fork offset [mm]:
0 mm
Fork total length [mm]:
0 mm
Head tube angle:
70 degrees
Head tube length [mm]:
180 mm
Reach [mm]:
404 mm
Stack [mm]:
643 mm
Stand over height [mm]:
0 mm
Seat tube angle:
71 degrees
Seat tube length [mm]:
410 mm
Top tube length [mm]:
620 mm
Wheelbase [mm]:
1140 mm
Brake system
Brake Front Description:
Shimano, Freno de disco hidráulico, MT410, 180 mm
Brake Rear Description:
Shimano, Freno de disco hidráulico
Carrier
Max Weight Carrier Rear:
25 kg
Carrier Rear Description:
Winora, MIK, system carrier
Drivetrain
Cassette Teeth:
11-48T
Crankset Teeth:
38T
Crankset Type:
single
Number Of Gears:
10
Bottom Bracket Description:
integrated in the motor
Cassette Description:
MicroSHIFT, X HG104-10
Chain Description:
KMC, Cadena, e10S
Chain Guard Description:
SKS, Chainbow-E 38T
Crankset Description:
Samox, aluminium crank
Derailleur Rear Description:
MicroSHIFT, Advent X RD-M6205M, 10s
Gear Description:
MicroSHIFT, Derailleur
Pedal Description:
VP, E461
Shifter Right Description:
MicroSHIFT, Triggershift, Advent X SL-M9505-R
E-bike components
Battery Capacity:
500 Wh
Battery Location:
Powertube
Battery Removeable:
Si
Display Removeable:
Retirable
Motor Torque [nm]:
75 Nm
Motor Location:
Center
Battery Description:
Bosch, InTube 500 Wh
Charger Description:
Bosch, standard charger 4 Ah
Motor Description:
Bosch
Frame and more
Framesize Convection:
XS
Max loadable weight (KG):
130 kg
Front Fork Type:
Suspension
Front Fork Description:
Suntour, NEX E25 60 mm
Frame Description:
Low, Aluminio, Unisex
Stand Description:
Ursus, Single, Mooi Rear Stand
Handlebar and Saddle
Ring:
Si
Seatpost Material:
Aluminio
Stem Adjustable:
Si
Handgrip Description:
Velo, Ergogriffe
Handlebar Description:
Winora, Ergobar, oversize
Headset Description:
VP, J213PE
Saddle Description:
Selle Royal, Wave
Seatpost Description:
XLC, Suspension, Patent, Dia. 31.6 mm
Stem Description:
Winora, A-Head, angle adjustable, Dia. 31.8 mm
Lighting
Front Light Description:
Herrmans, MR5
Rear Light Description:
AXA, Juno Ebike
Locks
Lock Description:
Abus, Ring lock, upgradable over Plus System
Other
Suitable For Childseat:
Si
Wheels and wheel components
Tamaño de la rueda en pul:
28
Hub Front Description:
Winora, alu hub
Hub Rear Description:
Winora, alu hub
Mudguard Front Description:
EuroFender, Tempo, Chromoplastic
Mudguard Rear Description:
EuroFender, Tempo, Chromoplastic
Rim Description:
Ryde, Hollow rim, Eco21
Spoke Description:
Sapim, Leader
Tyre Description:
XLC, Traverse CTC, 50-622
Wheelsize Description:
28
